Step 6
å
Insert a METAL PIN (1R) into the edge of the SMALL BACK (H3).
å
Fasten the TOP (E2) to the UPRIGHT (C3). Tighten two
HIDDEN CAMS.
å
NOTE: Be sure the METAL PIN inserts into the hole in
the TOP (E2).
å
Turn a CORD CLIP (4P) into the hole in the bottom
surface of the TOP (E2).
411606 www.sauder.com/servicePage 10
Arrow
Minimum
190 degrees
Maximum
210 degrees
E2
C3
H3
1R
4P
Surface
with
holes
