Step 1
Look for this icon. It means a
video assembly tip is available at
www.sauder.com/service/tips
å
Assemble your unit on a carpeted fl oor or on the empty
carton to avoid scratching your unit or the fl oor.
å
Push fourteen HIDDEN CAMS (1F) into the ENDS (A2 and B2)
and BRACES (E, F, and, M67). Then, insert the metal end of a
CAM DOWEL (2F) into each HIDDEN CAM.
416407www.sauder.com/service
Page 5
Arrow
1F
2F
(14 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
A2
B2
E
F
M67
M67
M67
M67
To Next Page
