Pull the DRAWER FRONT BRACKETS (7G) apart and slide them into the
grooves in the DRAWER SIDES (D42 and D43). You may need to gently
tap them in with a hammer.
å
NOTE: The DRAWER FRONT BRACKETS are marked “RH” and “LH” for
easy identifi cation.
å
Fasten the DRAWER FRONT (K) to the DRAWER FRONT BRACKETS (7G).
Use two BLACK 9/16" LARGE HEAD SCREWS (1S).
Step 9
417771www.sauder.com/services
Page 13
K
D42
D43
Push down
BLACK 9/16" LARGE HEAD SCREW
(2 used in this step)
1S
7G
7G
To Next Page
