Step Step 8
å
Fasten the RIGHT END (A) to the TOP (D), BOTTOM (E),
SHELF (F), and VALANCES (K). Use thirteen 1-1/2" FLAT
HEAD SCREWS (18).
å
Fasten the RIGHT END (A) to the SKIRT (L). Use a 1/2"
PAN HEAD SCREW (18) through the ANGLE BRACKET
on the SKIRT and into the RIGHT END.
E
L
F
D
A
Edge with
HINGE BRACKETS
1/2" PAN HEAD SCREW
(1 used in this step)
18
1-1/2" FLAT HEAD SCREW
(13 used in this step)
13
Page 12 www.sauder.com 419188
K
K
