Sauder 419188 - Assembly Tools Required; Part Identification Guide

Table of Contents Assembly Tools Required
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
2-3
4
5-18
19-21
22-24
25-26
27
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D TOP (1)
E BOTTOM (1)
F SHELF (1)
G BACK (1)
H RIGHT DOOR (1)
I LEFT DOOR (1)
J ADJUSTABLE SHELF (4)
K VALANCE (2)
L SKIRT (1)
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
Now you know
our ABCs.
Part Identifi cation
Electric drill with 1/4" bit
(ONLY in indicated step)
Page 2 www.sauder.com 419188
