Step 16
421952 www.sauder.com/servicePage 20
å
IMPORTANT: You will need someone's help in this step.
å
Fasten the TOP (L) to the ENDS (A and B). Use ten BLACK 9/16" LARGE HEAD SCREWS (1S) through the LIFT TABLE
MECHANISMS (23M) and into the holes in the ENDS.
å
NOTE: Be careful when lining up the holes in the MECHANISMS with the holes in the ENDS as to not damage any parts.
You should start each SCREW a few turns before completely tightening any of them.
23M
23M
B
A
BLACK 9/16" LARGE HEAD SCREW
(10 used in this step)
1S
These four holes
must be here.
L
This hole will be used
in the next step.
This hole will be used
in the next step.
To Next Page
