Sauder 423033 - Step 6: Add Lower Left End and Bottom

Step 6
å
Fasten the LOWER LEFT END (D) to the SHELF (G2).
Tighten two HIDDEN CAMS.
å
Fasten the BOTTOM (F) to the LOWER LEFT END (D).
Tighten two HIDDEN CAMS.
423033 www.sauder.com/servicesPage 10
Arrow
Minimum
190 degrees
Maximum
210 degrees
Notched edge
Surface with
HIDDEN CAMS
G2
F
Surface with
HIDDEN CAMS
These holes
must be here.
D
