Sauder 423033 - Step 7: Attach Lower Right End and Moldings

å
Fasten the LOWER RIGHT END (C) to the BOTTOM (F)
and SHELF (G2). Tighten four HIDDEN CAMS.
å
Slide the LOWER END MOLDINGS (P)* onto the notched
edges of the LOWER ENDS (C and D).
å
* U.S. Patent No. 5,499,886
Step 7
423033www.sauder.com/services
Page 11
Arrow
Minimum
190 degrees
Maximum
210 degrees
Notched edge
Notched edge
C
D
P
P
Slide the LOWER END
MOLDINGS (P) onto
the notched edges.
G2
F
Surface without
HIDDEN CAMS
The large groove is
closer to this edge.
The large groove is
closer to this edge.
