Sauder 423033 - Step 3: Connect Top Panel

Step 3
423033www.sauder.com/services
Page 7
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
A2
B2
E2
Notched edge
Notched edge
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface with holes
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
å
Fasten the TOP (E2) to the ENDS (A2 and B2). Tighten
four HIDDEN CAMS.
Long fi nished edge
