Insert a WOOD DOWEL (15F) into the hole in the TOP (E2).
å
Fasten the BRACE (I) to the TOP (E2). Tighten two
HIDDEN CAMS.
å
NOTE: Be sure the WOOD DOWEL in the TOP inserts
into the hole in the LEG.
å
Fasten the MODESTY PANEL (G) to the LEFT REAR
LEG (X). Tighten three HIDDEN CAMS.
Step 11
Surface with holes
X
G
E2
I
15F
Surface with
HIDDEN CAMS
Curved edge
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
