IMPORTANT: Units that are stacked on top of another unit
must be attached to each other as indicated in this step.
These units must be positioned against a wall and the
upper unit must be attached to a wall.
å
You may need someone's help in this step.
å
Remove the SKIRTS from the upper unit.
å
Fasten the upper unit to the lower unit. Use two SILVER
1-1/8" FLAT HEAD SCREWS (10S) through the holes in
the underside of the TOP (C) and into the BOTTOM (D).
å
NOTE: The holes in the TOP are not through holes. Use a
little extra force while turning these SCREWS.
Step 11
411591www.sauder.com/services
Page 15
STACKING OPTION:
(If not stacking units, go to Step 12)
C
D
SILVER 1-1/8" FLAT HEAD SCREW
(2 used in this step)
10S
To Next Page
