Sauder Transit 414417 - Step 7: Connect Lower Top Panel; Attach Lower Top to Back Panel; Attach Lower Top to Desk Frames

å
Fasten the LOWER TOP (F2) to the LOWER BACK (M).
Tighten four HIDDEN CAMS.
å
Fasten the LOWER TOP (F2) to the DESK FRAMES (V).
Use six BLACK 3/4" PAN HEAD SCREWS (85S).
Step 7
414417www.sauder.com/services
Page 11
F2
V
V
F2
M
M
Surface with
more holes
Surface with
HIDDEN CAMS
Arrow
Minimum
190 degrees
Maximum
210 degrees
This hole should be here.
Surface with
HIDDEN CAMS
BLACK 3/4" PAN HEAD SCREW
(6 used in this step)
85S
