Step 8
å
Fasten the UPRIGHT (C) to the TOP (H2). Tighten two
HIDDEN CAMS.
å
Push the MAGNETIC CATCH (2I) into the hole on
the TOP (H2).
414417 www.sauder.com/servicesPage 12
H2
C
2I
Surface with holes
Surface with
HIDDEN CAMS
Arrow
Minimum
190 degrees
Maximum
210 degrees
These holes should be here.
Large hole
Don't worry. It isn't
Rome. This can be built
in a day.
Part (H2). Another sturdier,
easier, friendlier component!
