Sauder Transit 414417 - Step 9: Assemble Divider and Uprights; Insert Metal Pins into Divider; Connect Divider to Upright; Fasten Center Upright

å
Insert four METAL PINS (1R) into the DIVIDER (U).
å
Insert the METAL PINS (1R) in one end of the DIVIDER (U)
into the holes in the UPRIGHT (C).
å
Fasten the CENTER UPRIGHT (D) to the TOP (H2).
Tighten two HIDDEN CAMS.
å
NOTE: Be sure the METAL PINS in the DIVIDER insert into
the holes in the CENTER UPRIGHT.
Step 9
414417www.sauder.com/services
Page 13
C
U
H2
D
1R
Arrow
Minimum
190 degrees
Maximum
210 degrees
Surface without
HIDDEN CAMS
Finished edge
Finished edge
