Sauder Transit 414417 - Step 10: Attach Lower End and Desk Back; Fasten Lower End and Desk Back to Top; Adjust Extension Rail for Tightening

Step 10
å
Fasten the LOWER END (A) and DESK BACK (L) to the
TOP (H2). Tighten fi ve HIDDEN CAMS.
414417 www.sauder.com/servicesPage 14
H2
L
A
Surface with
HIDDEN CAMS
If needed, loosen this SCREW
and slightly raise the EXTENSION
RAIL to tighten the HIDDEN CAM.
Tighten the SCREW when fi nished.
Arrow
Minimum
190 degrees
Maximum
210 degrees
Surface with
HIDDEN CAMS
Finished edge
HIDDEN CAM
EXTENSION RAIL
