Sauder Transit 414417 - Step 16: Assemble Drawer Components; Fasten Pull to Drawer Bottom; Attach Drawer Sides to Bottom; Fasten Drawer Back to Sides

Step 16
å
Fasten the PULL (21K) to the DRAWER BOTTOM (T). Use
two BLACK 1/2" FLAT HEAD SCREWS (11S).
å
Fasten the DRAWER SIDES (R and S) to the
DRAWER BOTTOM (T). Use four BLACK 1-7/8"
FLAT HEAD SCREWS (2S).
å
Fasten the DRAWER BACK (Q) to the
DRAWER SIDES (R and S). Use
two BLACK 1-7/8" FLAT
HEAD SCREWS (2S).
414417 www.sauder.com/servicesPage 20
T
Surface with
more holes
21K
Surface without PULL
T
Q
R
S
Finished edge
These surfaces should be the same color.
Surface and edge
with HIDDEN CAM
Surface and edge
with HIDDEN CAM
BLACK 1-7/8" FLAT HEAD SCREW
(6 used in this step)
2S
BLACK 1/2" FLAT HEAD SCREW
(2 used in this step)
11S
The PULL on the other
side is closer to this edge.
