Fasten the HUTCH ENDS (B) to the HUTCH TOP (G).
Tighten four HIDDEN CAMS.
Step 3
414417www.sauder.com/services
Page 7
B
B
G
Surface with holes
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Surface with
HIDDEN CAMS
Long fi nished edge
Surface with
HIDDEN CAMS
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
