9
DKMH.PS.315.B1.02 520L0535
Series 20 – Axial Piston Pumps
Service Manual and Repair Instructions
Start-up procedure
P000 337E
Gauge port -
servo cylinder pressure
(both side)
Control handle
Gauge port "M":
Charge pressure
Port "S":
Suction port
(charge pump)
Port "A"+"B":
High pressure
Case drain
p
orts
