sauermann SI-1801 - Page 4

4
Ø 40 mm, 1 1/2’’
Ø 32 mm, 1 1/4’’
Ø 24 - 25 mm, 1 ’’
Ø 20 mm, 3/4’’
Ø 15 - 17 mm, 5/8’’
B
Fig. 6
M6 max.
Fig. 7
IN
B
ACC02040
Ø 30 mm
Ø 1 3/16 ’’
262 mm - 10 5/16’’ 107,5 mm
4 1/4’’
A.
B. C.
