sauermann Si-82 - Technical Specifications; SI8200 SCUN23, SI1800 SCUN23, SI1802 CUN23, SI1802 SCAN23; SI1800 SCUS11, SI1800 SCUS23, SI1802 SCUS11, SI1802 SCUS23; Safety Warnings

8
The SI1800 or Si-82 centrifugal monobloc pumps are designed for use with all kinds of Air conditioning
units, refrigeration display cabinets, fan coil units and condensing boilers. They can also be used with gas
red furnaces. The pump can be used to remove acid condensates (pH > 2.5) and condensates with a
temperature of up to 65°C.
Vertical
discharge
head
Total tubing length
5 m 10 m 20 m 30 m
1 m 380 300 240 190
2 m 310 260 200 150
3 m 240 200 145 110
4 m 150 130 80 60
5 m 30 20 0 0
The head losses dened in these tables are calculated
with a Ø 10 mm int. hose.
EN
Vertical
discharge
head
Total tubing length @ 50 / 60 Hz
16 ft
(5 m)
30ft
(10 m)
60ft
(20 m)
100ft
(30 m)
3 1/4ft (1 m) 100 92 74 61
6 1/2ft (2 m) 82 75 61 50
10ft (3 m) 65 58 48 38
13ft (4 m) 50 42 36 28
16ft (5 m) 30 /37 26 /29 21 /22 16 /17
18ft (5.5 m) 11 /20 8 /13 5 /11
Actual flow rates (l/h)
Mains supply
230V~ 50Hz - 70 W - 0.67 A
Safety switch NC 4 A resistive - 250V
Max. ow rate 500 l/h
Max. discharge head 5.0 m
Operating time S3: 30% (3 s ON – 7s OFF)
Noise level in application 45 dBA at 1 m (3.3 ft)
Water levels (mm) Fig. 4
Max. condensate tempera-
ture & acidity
t<65°C, pH>2.5
Reservoir volume 2.0 l
Thermal protection
(overheat)
105°C (auto-reset)
Protection IP 20
WARNING
- This pump has been designed for use with water only.
- This pump has been designed for indoor use only. It must not be immersed and/or placed in areas of high
humidity or where the ambient temperature conditions are below freezing.
- The appliance is not to be used by children or persons with reduced physical, sensory or mental capabili-
ties, or lack of experience and knowledge, unless they have been given supervision or instruction.
- Children should be properly supervised to ensure they do not play with the appliance.
- In case of breakdown, in particular if the supply cord is damaged, it must be replaced by a Sauermann
service agent or a similarly qualied person in order to avoid any hazard.
- For models tted with a supply cord without a plug, a means for disconnection must be incorporated to the
xed wiring in accordance with local wiring rules.
WARNING: Risk of electric shock. This pump is supplied with a grounding cable and a grounding
attachment plug. To reduce the risk of electric shock, ensure that the pump is connected only to a suitable
grounding device.
Technical specification : SI8200SCUN23 - SI8200SCUN23
- SI1800SCUN23 - SI1802CUN23 - SI1802SCAN23
Mains supply
120V~ 60Hz - 85 W - 1.45 A (1) (3)
230V~ 50/60Hz - 80 W - 0.72 A
(2) (4)
Safety switch (3)(4) NC 4 A resistive - 42 V peak
Max. ow rate 132 gph (500 l/h)
Max. discharge head 21ft (6.4m) @ 60Hz
18ft (5.5m) @ 50Hz
Operating time S3: 30% (3 s ON – 7s OFF)
Noise level in application 45 dBA at 3.3 ft (1 m)
Water levels (mm) Fig. 4
Max. condensate
temperature & acidity
t<150°F (t<65°C) , pH>2.5
Reservoir volume 1/2 US Gal (2.0 l)
Thermal protection
(overheat)
248°F (120°C) (auto-reset)
Protection IP 20
Technical specification : SI1800SCUS11 (1) -
SI1800SCUS23 (2) - SI1802SCUS11 (3) - SI1802SCUS23 (4)
The head losses dened in these tables are calculated
with a Ø 1/4’’ (10 mm) int. hose.
Actual flow rates (gph)
