sauermann Si-83 - Page 2

2
Fig. 1
Fig. 2
SI83CE01UN23 - SI83CE41UN23 - SI83CE71UN23 -
SI83CE04UN23 - SI83CE74UN23 : E
SI83CE02UN23 - SI83CE42UN23 : A, B
SI83CE43UN23 : A, B, F
SI83CE05UN23 : A, C, D
SI83CE07UN23: A, C, D
SI83UL02UN12 - SI83UL42UN12 - SI83UL72UN12 -
SI83UL02UN23 - SI83UL42UN23 - SI83UL72UN23 : B
SI83UL03UN12 - SI83UL03UN23 : A, B
C
ACC00908
Ø 10 - 20 mm
Ø 3/8’’ - 3/4’’
B
ACC00939
Ø 15/17 - 20 - 24/25 - 32 - 40 mm
Ø int 5/8’’- 3/4’’- 1’’- 1 1/4’’ - 1 1/2’’
6 mm (1/4’’)
E
A
D
Ø 10 - 10 mm
Ø 3/8’’ - 3/8’’
ACC00911
Ø 10 mm int - 25 m
Ø int 3/8’’- 82’
AL * : 48 mm (1 7/8’’)
OFF : 21 mm (0 13/16’’)
ON : 40 mm (1 9/16’’)
Fig. 3
PH0100SIUN23
F
App.
Si-83 mobile App
