Crane ChemPharma & Energy
Calibration DeviceNet
Output Byte 1
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Factory Reset Self Calibration Solenoid Command
Calibration with Integral Solenoid (DeviceNet)
Self-Calibration of M-VUE is controlled by Output Byte 1, Bit 2 on DeviceNet networks
By changing Bit 2 from 0 to 1, the M-VUE unit can perform its self-calibration cycle.
Calibration with External Solenoid (DeviceNet)
M-VUE can control a remote solenoid to cycle a pneumatic actuator and perform remote calibration.
• By changing Output Byte 1, Bit 2 from 0 to 1, the M-VUE unit can perform its self-calibration cycle.
• Input Byte 1, Bit 4 must be used to command a signal to control a remote solenoid.
• Value 0 is used to de-energize the remote solenoid
• Value 1 is used to energize the remote solenoid
The self-calibration sequence is automatic and will cycle the aseptic valve for three cycles.
Note: In order to perform a successful calibration after 3 seconds Bit 2 must be changed from 1 to 0
Warning: Self-Calibration will perform valve cycling and thus care must taken as the valve will move
Output Byte 1
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Factory Reset Self Calibration Solenoid Command
Input Byte 1
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Common Alarms
External Solenoid
Command
Calibration Status
Solenoid Forced at
the sensor
Open position Closed position
Note: In order to perform a successful calibration after 3 seconds Output Bit 2 must be changed from 1 to 0, otherwise the system
will not self-calibrate
Warning: Self-Calibration will perform valve cycling and thus care must taken as the valve will move
