Example 1 LOWER LIMIT= 0 N-m, UPPER LIMIT= 20 N-m
Load
The "UPPER" LED is on. Other LEDs are off.
Upper limit
The "OK" LED is on. Other LEDs are off
Time
Example 2 LOWER LIMIT= 20 N-m, UPPER LIMIT= 0 N-m
Load
The "OK" LED is on. Other LEDs are off.
Lower limit
The "LOWER" LED wants ON. Other LEDs are off.
Time
Example 3 LOWER LIMIT= 10 N-m, UPPER LIMIT= 20 N-m
Load
The "UPPER" LED is on. Other LEDs are off.
Upper limit
The "OK" LED is on. Other LEDs are off.
Lower limit
The "LOWER" LED is on. Other LEDs are off.
Time
