sauter DB - Technical Data

4 DB-BA-e-2020
5 Technical data
Torque tester
DB 0.5-4
DB 1-3
DB 5-3
DB 10-3
DB 20-3
DB 50-2
Maximum torque
0.5 Nm
15 Nm
5 Nm
10 Nm
20 Nm
50 Nm
Accuracy
(Composite error)
±0.5% of full scale range
Creep
±0.002 of full scale range
Non-linearity
±0.002 of full scale range
Temperature
fluctuation at zero
load
±0.002 of full scale range/°C
Operating
temperature
20±10°C
Storage and
transport
temperature
-15°C up to 65°C
Relative air humidity
Not more than 70
Torque tester
DB 50-2
DB 100-2
DB 200-2
DB 500-2
Maximum torque
50 Nm
100 Nm
200 Nm
500 Nm
Accuracy
(Composite error)
±0.5% of full scale range
Creep
±0.002 of full scale range
Non-linearity
±0.002 of full scale range
Temperature
fluctuation at zero
load
±0.002 of full scale range/°C
Operating
temperature
20±10°C
Storage and
transport
temperature
-15°C up to 65°C
Relative air
humidity
Not more than 70
