4.4 Technical Data FL TM
4.4.1 Sensors
Sensor must be ordered separately. Service FL-C01 necessary.
4.4.2 Load cell connection
Solder the cable from the measuring cell to the supplied connector. The pin
assignment at the connector is as follows:
Pin 1: Supply ( - )
Pin 2: Signal ( + )
Pin 3: Signal ( - )
Pin 4: Supply ( + )
Pin 1: EXC ( - )
Pin 2: Signal ( + )
Pin 3: Signal ( - )
Pin 4: EXC ( + )
Adjustable
measuring
ranges
5N; 10N; 25N;
50N; 100N;
250N; 500N
1kN; 2,5kN; 5kN;
10kN; 20kN;
50kN
Characteristic
value max.
1mV/V
2mV/V
Measurement
uncertainty
±0,2% bis 1% von Max
(Messbereich), abhängig von
verwendetem Sensor
Working
temperature
15°C bis 35°C
Weight display
unit
Ca. 500g
Dimensions
display unit
(LxWxH)
160x75x30mm
