Page 36 of 68
Termination above Roof
Consult local codes for minimum vent cap height above the roof (X), vent must be a minimum of 2’ from any
wall.
To prevent water seepage; install the flashing with upper portion under the roofing material and the lower
portion over the roofing material.
Note: Do not fasten down until the final adjustments to the vent have been made.
The diagram at right shows the
minimum clearances as per the
chart on page 36.
3.00
12.00
