Page 38 of 68
3.3.5 CERAMIC LOG INSTALLATION / INSTALLATION BÛCHES EN CÉRAMIQUE
The burner pan has 5 pins for positioning the log placement. Please follow instructions carefully and
accurately as this will prevent soot buildup on the logs.
Position the 1
st
log on back log pins, make sure the cutout fits over the pilot assembly as shown.
Position 2
nd
log at left end of back log, make sure log fits on pin at left side of burner pan.
CAU TION
ATTENTION
Burn medium positions are critical to the safe and clean operation of this appliance.
Never add any other material into the firebox. Use only with burn medium supplied
with this unit.
Burn positions moyennes sont critiques pour le fonctionnement sûr et propre de cet
appareil. Ne jamais ajouter d'autres matériaux dans le foyer. Utilisez uniquement
graver moyen fourni avec cet appareil.
