SawStop 10” Industrial Cabinet Saw 3
Table of Contents
5. Using the Saw in Bypass Mode: 33
6. Using the Blade Guard: 34
7. Using the Riving Knife: 35
8. Using the Miter Gauge: 35
9. Cross-Cutting: 37
10. Rip Cutting: 38
11. Changing the Brake Cartridge: 40
What to do if the SawStop Safety System Activates 45
Making Adjustments to Your Saw 46
1. Aligning the Table: 46
2. Aligning the Blade Elevation Assembly: 50
3. Aligning the Blade to the Tilt Axis: 52
4. Adjusting the Elevation Limit Stops: 56
5. Adjusting the Tilt Limit Stops and Tilt Angle Indicator: 58
6. Adjusting the Table Insert: 60
7. Aligning the Riving Knife and Spreader to the Blade: 62
8. Adjusting the Quick-Release Clamp: 64
9. Adjusting the Tilt Gearing: 65
10. Adjusting the Miter Gauge: 66
Cabinet Saw Specications 67
Maintenance 68
1. SawStop Safety System: 68
2. Cabinet: 68
3. Elevation and Tilt Mechanisms: 68
4. Table and Extension Wings: 68
5. Belts: 68
Troubleshooting 69
Cabinet Saw Dimensions 73
Push Stick Construction 75
