SLIDING CROSSCUT TABLE INSTALLATION
No.
TSA-SA48Sliding Table Assembly
103 TSA-SA48-103M6x1.0x12 Pan Head Socket Screw
102 TSA-SA48-102Sliding Table End Cover
105 TSA-SA48-105Sliding Table Limit Block
104 TSA-SA48-104Sliding Table Lock Knob
107 TSA-SA48-107M8 Lock Washer
106 TSA-SA48-106M8x1.25x35 Socket Head Cap Screw
109 TSA-SA48-109M8x1.25x35 T-Bolt
108 TSA-SA48-108M8x16x1.8 Washer
111 TSA-SA48-111Sliding Table Extension Table
110 TSA-SA48-110M8x1.25 Lock Nut
113 TSA-SA48-113Switch Box Mounting Bracket
112 TSA-SA48-112Extension Table End Cover
115 TSA-SA48-115M6 Lock Washer
114 TSA-SA48-114M6x1.0x16 Socket Head Cap Screw
117 TSA-SA48-117M6x1.0 Nut
116 TSA-SA48-116M6x12x1.5 Washer
118 TSA-SA48-118M10x1.5x35 Socket Head Cap Screw
120 TSA-SA48-120Foot
119 TSA-SA48-119Support Leg
122 TSA-SA48-122M10 Lock Washer
121 TSA-SA48-121M10x1.5x25 Socket Head Cap Screw
128 TSA-SA48-128Bearing Rails
123 TSA-SA48-123M10x20x3 D-Style Washer
130 TSA-SA48-130Felt Swipe
129 TSA-SA48-129Ball Bearing
132 TSA-SA48-132M6x1.0x18 Flat Head Socket Screw
131 TSA-SA48-131Sliding Table Bump Stop
134 TSA-SA48-134M6x1.0x16 Flat Head Socket Screw
133 TSA-SA48-133Limit Block Bump Stop
202 TSA-SA48-202Crosscut Fence Extension Support Plate
201 TSA-SA48-201Crosscut Fence Extension Sub Assembly
204 TSA-SA48-204Crosscut Fence Extension Glides
203 TSA-SA48-203M6x1.0x10 Socket Head Cap Screw
206 TSA-SA48-206Crosscut Fence Extension Bar
205 TSA-SA48-205M6x1.0x10 Set Screw
209 TSA-SA48-209Crosscut Fence Extension Ruler Assembly
207 TSA-SA48-207M6 Spring Bearings
212 TSA-SA48-212Flip Stop Bar
211 TSA-SA48-211M4x0.7x8 Socket Head Cap Screw
214 TSA-SA48-214Flip Stop Lock Block
213 TSA-SA48-213M4x0.7x16 Socket Head Cap Screw
216 TSA-SA48-216M8x1.25x12 Socket Head Shoulder Screw
215 TSA-SA48-215M6 Flip Stop Lock Knob
218 TSA-SA48-218M4x0.7x10 Nylon Screw
217 TSA-SA48-217M8x16x1.5 Nylon Washer
220 TSA-SA48-220Stop Plate Mounting Block
219 TSA-SA48-219Crosscut Fence Flip Stop
221 TSA-SA48-221Flip Stop Position Indicator Lens
223 TSA-SA48-223Crosscut Fence Extension Indicator Lens
222 TSA-SA48-222Crosscut Fence Sub Assembly
225 TSA-SA48-225Crosscut Fence Ruler Assembly
227 TSA-SA48-227Crosscut Fence Lock Knob
Part No.Description No.
229 TSA-SA48-229Crosscut Fence Lock Bar
228 TSA-SA48-228M8x28x3 Nylon Washer
231 TSA-SA48-231Crosscut Fence Extension Knob Mounting Block
230 TSA-SA48-230Crosscut Fence Glide Pad
233 TSA-SA48-233Crosscut Fence Extension Lock Knob
232 TSA-SA48-232M4x0.7x10 Socket Head Cap Screw
235 TSA-SA48-235M16x2.0 Lock Nut
234 TSA-SA48-234Crosscut Fence Miter Gauge Cover
237 TSA-SA48-237M16x31x0.7 Spring Washer
236 TSA-SA48-236M16x32x3 Washer
239 TSA-SA48-239M6x1.0 Square Nut
238 TSA-SA48-238Crosscut Fence Pivot Bushing
242 TSA-SA48-242M4x9x0.8 Washer
240 TSA-SA48-240M6x1.0x20 Socket Head Cap Screw
244 TSA-SA48-244M4x0.7x20 Socket Head Cap Screw
243 TSA-SA48-243M4 Lock Washer
246 TSA-SA48-246Miter Gauge Angle Indicator Lens
245 TSA-SA48-245M4x0.7x12 Button Head Socket Screw
248 TSA-SA48-248M8x1.25x8 Flat Head Screw
247 TSA-SA48-247Miter Gauge Lens Mounting Block
250 TSA-SA48-250M4x0.7x14 Socket Head Cap Screw
249 TSA-SA48-249Miter Gauge Bar
252 TSA-SA48-252Miter Gauge Pivot Shaft
251 TSA-SA48-25116mm External Retaining Ring
257 TSA-SA48-2572” Grommet For CNS Saws
253 TSA-SA48-253M6 Lock Washer
259 TSA-SA48-259Flip Stop Lock Block Spring
258 TSA-SA48-258M6x1.0x6 Set Screw
262 TSA-SA48-262Miter Gauge Glide Pad Bushing Sub Assembly
261 TSA-SA48-261M16 Miter Gauge Oval Washer
264 TSA-SA48-264Flip Stop Assembly
263 TSA-SA48-263Miter Gauge Glide Pad
265 TSA-SA48-265M8x1.25 Hex Nut
266 TSA-SA48-266Allen Wrench Kit
267 TSA-SA48-267Open End Wrench
268 TSA-SA48-268Open End Wrench and Allen Wrench Kit
269 TSA-SA48-269Complete Hardware Pack
270 TSA-SA48-270Sliding Crosscut Table Installation Guide
271 TSA-SA48-271M10x1.5 Lock Nut
272 TSA-SA48-272Bearing Rail Retainer (Left)
274 TSA-SA48-274Bearing Rail Retainer (Center)
273 TSA-SA48-273Bearing Rail Retainer (Right)
275 TSA-SA48-275M5x0.8x10 Button Head Socket Screw
276 TSA-SA48-276M5x0.8x12 Flat Head Socket Screw
Part No.Description
Sliding Table Attachment Parts List:
