21
SLIDING CROSSCUT TABLE INSTALLATION
1. To adjust the crosscut miter angle, loosen the crosscut fence lock knob to allow the crosscut fence to pivot.
Using the miter gauge angle indicator, set the fence to the desired miter angle and retighten the lock knob to
secure the fence in place.
2. To make repetitive cuts, loosen the appropriate ip stop lock knob and slide the ip stop into the desired
position. Retighten the lock knob to lock the ip stop in place.
3. Unlock the sliding table by pulling out the sliding table lock knob on the underside of the sliding table and
rotating it 90 degrees.
4. To prevent the sliding table from moving, pull out the sliding table saw lock knob and rotate it 90 degrees.
Next, slowly slide the table toward the Home Position until the lock pin engages and the table locks in place.
When the sliding table is not in use, lock it in place so that it will not move unexpectedly.
5. For longer work pieces (up to 60”), make sure the fence is positioned over the extension table. Next,
loosen the crosscut fence extension lock knobs (233) and slide the fence extension to the left as needed to
accommodate the longer work piece. Retighten the fence extension lock knobs.
If using the rulers on the fence or fence extension to position the ip stops, you should
reposition the rulers after changing the miter angle.
OPERATIONS
