SawStop tsa-sa48 - Mounting Options; Flush Mounting Without Left Wing; Standard Mounting Without Left Wing

5
SLIDING CROSSCUT TABLE INSTALLATION
mounting options
Option 1 of 4
Start on Page 13
This conguration minimizes the total footprint of the table saw and crosscut table, but the
ripping length is reduced from 48 inches to 37 inches. Since the left wing is not installed,
the crosscut table is close to the saw blade.
FLUSH MOUNTING
WITHOUT LEFT WING
This conguration provides the maximum ripping length and the closest position of the Crosscut
Table to the saw blade.
STANDARD MOUNTING
WITHOUT LEFT WING
Option 2 of 4
Start on Page 13
The SawStop Sliding Crosscut Table can be mounted to your SawStop table saw in any of four different
congurations depending on your needs.
