15
FRAME PIVOT SPECIFICATIONS
B = Blue Loctite required
Part#
1.a
1.b
1.c
1.d
1.e
1.f
1.g
1.h
1.k
1.m
1.n
Qty
2
4
2
4
2
2
4
2
2
2
6
Part Description
BB Bearing
Dropout Bearing
S- Link @ Frame Bearing
S- Link @ Seatstay Bearing
S- Link @ Clevis Bearing
BB Spacer
Dropout Outer Spacer
Dropout Inner Spacer
S-Link @ Frame Spacer
S-Link @ Clevis Spacer
S-Link @ Seatstay Spacer
Part Specification
1524F Full Complement Bearing - 24mm O.D. x 15mm I.D. x 5mm Width
6800-2RS Bearing - 19mm O.D. x 10mm I.D. x 5mm Width
1524F Full Complement Bearing - 24mm O.D. x 15mm I.D. x 5mm Width
6800-2RS Full Complement Bearing - 19mm O.D. x 10mm I.D. x 5mm Width
608-2RS Bearing - 22mm O.D. x 8mm I.D. x 7mm Width
Alloy Spacer - 20mm O.D. x 15mm I.D. x 3mm Width, Chamfered
Alloy Spacer - 16mm O.D. x 10mm I.D. x 2mm Width, Chamfered
Alloy Spacer - 16mm O.D. x 10mm I.D. x 3mm Width, Dual Chamfered
Alloy Spacer - 20mm O.D. x 15mm I.D. x 3mm Width, Chamfered
Alloy Spacer - 14mm O.D. x 8.5mm I.D. x 2.5mm Width, Inner Chamfered
Alloy Spacer - 16mm O.D. x 10mm I.D. x 2mm Width, Chamfered
Part#
2.a
2.b
2.c
2.d
2.e
2.f
2.g
2.h
2.h
2.k
2.m
2.n
2.o
2.p
2.q
2.r
2.s
2.t
Qty
1
2
1
2
2
2
1
1
1
2
2
2
1
1
1
1
1
1
Part Description
BB Axle
Dropout Bolt
S- Link @ Frame Axle
S- Link @ Seatstay Bolt
S-Link @ Clevis Bolt
S-Link @ Clevis Axle
Clevis @ Shock Axle
Upper Shock Eye Bolt (Carbon frame)
Upper Shock Eye Bolt (Alloy frame)
Dropout Washer
S-Link @ Seatstay Washer
S-Link @ Clevis Outer Washer
Upper Shock Eye Washer
BB Nut
S-Link @ Frame Nut
Clevis @ Shock Nut
Upper Shock Eye Nut (Alloy frame)
Upper Shock Eye Bolt Cover (Alloy frame)
Part Specification
Alloy Axle - M15 Thread x 64.5mm Shaft Length, 8mm Allen Hex Head
Alloy Bolt - M10 Thread x 29.5mm Shaft Length, 4mm Allen Hex Head
Alloy Axle - M15 Thread x 66mm Shaft Length, 8mm Allen Hex Chamfered Head
Alloy Bolt - M10 Thread x 28mm Shaft Length, 4mm Allen Hex Head
Steel Bolt - M6 Thread x 6.8mm Shaft Length, 4mm Allen Hex Chamfered Head
Ti Bolt - M10 Outer / M6 Inner Thread x 21mm Shaft Length, 6mm Allen Hex Head
Alloy Axle - M15 Thread x 28mm Shaft Length, 8mm Allen Hex Head
Steel Bolt - M8 Thread x 55mm Shaft Length, 4mm Allen Hex Head
Steel Bolt - M8 Thread x 40mm Shaft Length, 4mm Allen Hex Head
Steel Washer - 19.5mm O.D. x 10mm I.D. x 0.3mm Width
Steel Washer - 19.5mm O.D. x 10mm I.D. x 0.3mm Width
Alloy Washer - 21.5mm O.D. x 8mm I.D. x 5mm Thick, Chamfered
Steel Washer - 13.8mm O.D. x 8mm I.D. x 0.3mm Width
Alloy Nut - M15 Thread x 23.5mm O.D. (use 6-point 19mm socket)
Alloy Nut - M15 Thread x 23.5mm O.D. (use 6-point 19mm socket)
Alloy Nut - M15 Thread x 24mm O.D. , 6mm Thick, slots into frame
Alloy Nut - M8 Thread x 16mm Thick, slots into frame
Alloy Bolt Cover - 15mm O.D. x 7mm I.D.
Torque in*lb
200-230 B
120-140 B
200-230 B
120-140 B
120-140 B
120-140 B
200-230 B
70-90 B
70-90B
