4
ASSEMBLY
Distance to flammable walls
Positioning your wood-burning stove
The wood-burning stove must be set up so that the stove itself, the
flue pipe, and the chimney can all be cleaned.
Position in relation to non-flammable walls
When positioning near a non-flammable wall, keep a minimum
distance of 50mm between the rear of the product and the wall.
2
0
0
200
2
0
0
400
Distance to furniture: 800 mm
But please check to avoid furniture or other furnishings being dried
out due to being too close to the stove.
45° Corner installation
Parallel rear wall installation
1
0
2
1
2
2
7
*
*
*
9
0
0
*
9
9
0
*
*
510 510
2
5
5
Scan 50
1
1
4
1
510
2
2
7
*
*
*
9
0
0
*
2
5
5
1
1
1
0
*
*
510
Scan 50 Maxi
Note:
The Scan 50-5 Maxi is 5 mm taller than the Scan 50 Maxi.
Note:
The Scan 50-5 is 5 mm taller than the Scan 50.
* Centre rear outlet
** Height to the beginning of
the flue pipe at top outlet
*** Centre fresh air intake
* Centre rear outlet
** Height to the beginning of
the flue pipe at top outlet
*** Centre fresh air intake
