SCAN 67 - Requirements for Chimney; Distance to Furniture; Safety Distance

11
NAVN:
STI:
DIMENSION:
MATERIALE:
DATO:
SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg
©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan 67\90067015.idw
90067015
Ovn med buet knærør
28-01-2022
KEN
Scan 67
VÆGT:
AREAL:
257,27 kg
28689967 mm^2
REQUIREMENTS FOR CHIMNEY
The chimney must have a minimum internal diameter of 148 mm and have a T400 designation, with G for the soot fire test. The
length should be min. 4 metres.
If you opt to connect the stove with an elbow pipe, you should use a curved elbow, as this gives a better draught.
If you connect the stove with a sharp elbow pipe, the cleansing lid must be placed in the vertical
part so that the horizontal part can be cleaned through here.
If the chimney is fitted with a smoke extractor, it must be possible to adjust it to a suitable draft.
The requirements to the chimney and the flue pipe in terms of safety distances must be met.
¬ Choosing the wrong length or diameter of chimney could impair functionality
¬ Always comply exactly with the instructions provided by the chimney supplier
¬ The stove is not prepared for a balanced chimney, in which case the warranty is invalid
DISTANCE TO FURNITURE
Distance to furniture from glass: 1100 mm.
You should however assess whether furniture or other items might become excessively dry due to being too close to the stove.
SAFETY DISTANCE
European, national and local regulations concerning safety distances for wood-burning stoves must be complied with.
The stove must be set up so that the stove itself, the flue pipe, and the chimney can all be cleaned.
