Remove the cover.
This is to be used later as a seal and cover at the top
of the smoke outlet
Cover
Unscrew the stove’s heat shield and remove it.
Using cutting pliers, cut off the cover plate from the rear
plate and at its securing points
Unscrew the stove’s connecting piece and remove it
FITTING THE FLUE CONNECTION PIECE
The stove is prepared from the factory for top outlet for inside flue pipe.
Heat shield
IN THE REAR OUTLET
