9
ASSEMBLY
TOOLS NEEDED FOR MOUNTING OF THE STOVE
¬ Spirit level ¬ Combo wrench 8 mm
¬ Cutting nippers ¬ 3 allen keys (2,5 mm, 4 mm & 5 mm)
LOOSE PARTS
In the stoves combustion chamber you will find the following loose parts:
¬ Glove ¬ Connecting piece 148 cm for outside flue pipe
¬ Seal for the connecting piece ¬ Dekor plate for top plate
¬ USB-C charger cable for Zensoric control ¬ Eco energy label
ADDITIONAL ACCESSORIES
¬ Small shaped floor plate in glass ¬ Large shaped floor plate in glass
¬ Scan 67 1300 cm: Heat accumulating stones ¬ Scan 67 1600 cm: Heat accumulating stones
(2 items approx. 21 kg) (5 items approx. 52,5 kg)
¬ Handle - 7 different kinds
DISPOSAL OF PACKAGING
Your Scan stove may come supplied with the following packaging:
Wood packaging
The wood packaging can be reused and after final use can be incinerated as a CO
2
neutral
product or sent for recycling
Foam Send for recycling or waste disposal
Plastic bags Send for recycling or waste disposal
Stretch/plastic film Send for recycling or waste disposal
FRESH AIR INTAKE
In a well-insulated house, the air used up by the burning process has to be replaced. This particularly applies to houses with
mechanical ventilation. There are different ways of making sure that an air exchange takes place. The most important thing is to
ensure that there is a supply of air to the room where the wood stove is located. The external wall vent must be located as close
to the wood stove as possible, and you must be able to close it when you are not using the wood stove.
National and local building regulations must be followed with regard to the connection of fresh-air intake.
