INSTRUCTIONS FOR USE
Baffle plates
Ash container
Tertiary holes
SETTINGS
FOR NORMAL LOAD:
20 - 80%
Air control
button/
LED indicator Charging input
1 green blink = air damper test OK
1 green blink repeated every 8 seconds = re-firing signal
2 blue blink repeated every 8 seconds = recharge battery
1 red blink = air damper fault
2 red blink = battery level low, Zensoric switches off
3 red blink = temperature gauge fault
When charging:
Continuous red = charging
LED goes out = fully charged
No blinking at first opening of cold stove =
fault on door sensor
In case of error - contact the dealer of the stove
ZENSORIC SIGNAL GUIDE
The reset function is done by connecting the supplied
USB-C charger plug at the bottom of the side of the stove
and the 5V power supply in the socket.
Next, unplug after 30 sec. and open the door
and the Zensoric resets
RESET ZENSORIC
