21
Air Tube removal:
Remove the screw (pos.1) on the left air tube collar (pos.3).
Slide the air tube (pos.2) to the right, swing it down and remove
it.
Replacement Part List SCAN A10
Caution:
Use only original SCAN A10 replacement part.
Do not use substitute materials.
Replacement part Part #
Glass panel for the door 57811011
Gasket for the glass 55300023
Door gaskets 55300014
Baffle plate upper 54811000 091
Baffle plate lower 54811000 0911
Firebox lining 53811000 091
Upper part for shaking grate 50100110
Shaker grate, complete 50100111
Secondary air tube
