1 Ashtray. When you open the door, you have access to the
ashtray, which is placed below the combustion chamber.
Attention! Be careful when you empty ashes from the stove.
There may be embers left for up to 24 hours after the stove
was last used.
2 Handle for shaking grate. The stove is equipped with a shaking
grate. When you activate the grate handle, the ashes from the
combustion chamber are emptied into the ashtray.
3 Regulation for primary air. Turn the air valve in order to open.
The primary air is used when lighting and refuelling the stove. It
should always be closed during continuous firing.
4 Regulation for combustion air. Push the button sideways. Left
position is closed and right position is open. The air is used for the
combustion and regulates the output of the stove.
The ashtray, shaking grate, and primary air should always be
closed during continuous firing.
3
2
1
4
Scan Andersen 4-5
You should read this manual as well as the General Instructions for Installation before beginning the installation.
Mounting of the side covering:
Base:
Convection plates:
Soap stones:
