2.2 Main Specification
Bench Floor
Chuck Capacity
16 mm
16 mm
Distance, Spindle to column
190 mm
190 mm
Max.Spindle travel
80 mm
80 mm
Max.distance chuck to table
480 mm
745 mm
Max.distance chuck to base
745 mm
1235 mm
Overall dimensions (LXMXH)
1065x650x305 mm
1635x610x365 mm
Net Weight
61 KGS
67 GS
Range of spindle speeds (12 speeds)
Motor Speed
Spindle Speeds (min-1)
50Hz
1400 min-1
180
250
300
400
480
580
970
1280
1410
1540
2270
2740
60Hz
1700 min-1
250
340
390
510
600
650
990
1550
1620
1900
2620
3100
2.3 Unpacking and checking contents
1. Unpacking and checking contents: Separate all the parts from packaging materials and check each item
make sure all items are accounted for before discarding any packing material.
Following tables names the pieces in the graphic below.
Part
Description
No.
A
Table (square or Round )
1
B
Column Support Asm
1
C
Owner's Manual
1
D
Box of Loose Parts
1
E
Bag of Loose Parts (see list
below)
1
F
Base
1
G
Head Asm
1
2. Remove the protective oil that is applied to the table and column. Use any ordinary household type
grease and spot remover
3. Apply a coat of paste wax to the table and column to prevent rust. Wipe all parts thoroughly with clean
dry cloth.
