FIGURE 4 PARTS LIST
Key
No.
Description
Key
No.
Description
1
knob-Motor Adjusting
23
Seat-Spring
2
Screw-Socket Set M10*1.5-12
24
Retainer-Spring
3
Handle-Belt Tension
25
Spring-Torsion
4
Pin-Stop
26
Cap-Spring
5
Ring
-Depth Stop W/Scale
27
Nut
-Hex M12*1.5-8
6
Lock-Depth Screw
28
Head w/Pointer and Trim
7
Hub
32
Tie-Wire
8
Guide Scale
33
Cord-Power w/Plug
9
Knob
36
Clamp
-Cord
10
Rod
37
Support-Motor Bracket
11
Lock-Washer-Ext M5
38
Screw-Hex HD M6*1.0*12
12
Screw-Pan HD M5*0.8-8
39
Washer 8*16*1.6
13
Box
Switch
40
Mount
-Motor
14
Screw-Pan HD M5*0.8-16
41
Cord-Motor
15
Switch-Locking
42
Nut-Hex M8*1.25
16
Screw-Pan HD M4.2*1.4-8
43
Motor
18
Key
-Switch
44
Nut
-Hex M12*1.75
19
Cover-Switch Plate
45
Lockwasher 1/2
20
Lead-Asm 3
46
Support-Motor Bracket
21
Screw-Set Special 10*1.5-27
47
Screw-Hex HD M8*1.25-16
22
Nut
-Hex M10*1.5
48
Lever
-Adjusting
