14
92
Disc 8mm
5437850
5437850
5437850
93
Suction box for exhaust system
2578909
2578909
2578909
94
Suction hose ø102 mm
6721303
6721303
6721303
95
Hose strap 90-110 mm
0233110
0233110
0233110
96
Spark box with exhaust system
0102224
0102224
0102524
97
Star M6
0233807
0233807
0233807
98
Rest for surface grinding
1055680
1055680
1055680
4. Technical Data
4.1 Technical Specifications
Model
50
50X
75
75X
100
100X
150
150X
Grinding belt
50x2000
50x2000
75x2000
75x2250
75x2500
75x2000
75x2250
75x2500
100x2000
100x2000
150x2000
150x2500
150x2000
150x2500
Motor 3x380-440
V 50 Hz
3,6 HK
3,6 HK
4,1 HK
4,8 HK
4,1 HK
4,8 HK
4,8 HK
4,8 HK
4,8 HK*
4,8 HK*
Class
IEC 34-1
IEC 34-1
IEC 34-1
IEC 34-1
IEC 34-1
IEC 34-1
IEC 34-1
IEC 34-1
IP Class
54
54
54
54
54
54
54
54
r/min.
2860
2860
2860
2860
2860
2860
2860
2860
Ampere
10,6/6,0
10,6/6,0
10.6/6.1
10.6/6.1
10.6/6.8
10.6/6,8
10.6/6.8
10.6/6.8
Cos 
0,91
091
0,91
0,91
0,91
0,91
0,91
0,91
Belt speed
30 m/s
30 m/s
30 m/s
30 m/s
30 m/s
30 m/s
30 m/s
30 m/s
Contact wheel
Ø200x50
Ø200x50
Ø200x75
Ø200x75
Ø200x100
Ø200x100
Ø200x150
Ø200x150
Fan motor
-
0,5 HK
-
0,5 HK
-
0,5 HK
-
0,5 HK
Weight 2000
50 kg
70 kg
60 kg
80 kg
70 kg
90 kg
80 kg
100 kg
Weight 2250
-
-
70 kg
90 kg
-
-
-
-
Weight 2500
-
-
90 kg
100 kg
-
-
110 kg
130 kg
*5,5 HP motor available.
The noise level for SCANTOOL belt grinding machine has been measured to 80 dB (A) according
to the measuring instruction in the note 561 from the Work Inspection Department on device of
technical aids.
4.2 Dimensions
Fig.: 4.2
Model
A
B
C
D
E
F
G
H
I
J
K
50-2000
995
660
945
830-970
605
635
365
395
392
306
86
