Characteristics | Versions
8 Versions
In addition to the standard version other versions can
be supplied as well:
• water-proof design IP X3
• vandal-resistant; lift design
according to lift category 1 and 2 as per
EN 81-71
7 Characteristics
TFT 480
Supply voltage 12 V … 27 V DC, smoothed
Current consumption 120 mA at 24 V
Resolution 480 x 272 pixel
Temperature range 0 °C … +60 °C
Display size 96 x 54 mm, 4.3“
LED lifespan 60 000 h
Control Dual/Gray/
7-segment via terminals
Control 1 out of n via terminals or Encoder
Compliance optional EN 81-70
TFT 640
Supply voltage 12 V … 27 V DC, smoothed
Current consumption 200 mA at 24 V
Resolution 640 x 480 pixel
Temperature range 0 °C … +60 °C
LED lifespan 60 000 h
Display size 116 x 87 mm, 5.6“
Control Dual/Gray/
7-segment via terminals
Control 1 out of n via terminals or Encoder
Compliance EN 81-70
TFT 800
Supply voltage 12 V … 27 V DC, smoothed
Current consumption 300 mA at 24 V
Resolution 800 x 480 pixel
Temperature range 0 °C … +60 °C
LED lifespan 60 000 h
Display size 152 x 91 mm, 7“
Control Dual/Gray/
7-segment via terminals
Control 1 out of n via terminals or Encoder
Compliance EN 81-70
