Schaller Automation VN 215/93 - Alarm Diagram

14
Wire break resistance for VN/2020
Alarm diagram for VN/87 EMC, VN/87plus & VN/93
Part numbers for wire break resistors:
Part no.:
Value K ohm:
Other information:
100900-33,00K
33,00 K ohm
2 pc. per package incl. instruction fact sheet
100900-33,20K
33,20 K ohm
2 pc. per package incl. instruction fact sheet
100900-24,90K
24,90 K ohm
2 pc. per package incl. instruction fact sheet
100900-10,00K
10,00 K ohm
2 pc. per package incl. instruction fact sheet
100900-3,30K
3,30 K ohm
2 pc. per package incl. instruction fact sheet
For more information about wire break resistance:
https://www.epp.no/exchange-pool/wire-break-resistance/
