Operating instructions Bus System SDTBUS 630 mit EBL 630 B
4
Date:14.12.2018 8110605 BA / EN
A bus-compatible IT ... or DT ... control and display panel must be connected to the EBL
630 B for operation. Bus modules are also required. Together these devices control the
electrical functions in the vehicle’s leisure area, including accessories.
It is also possible to connect up to 2 auxiliary chargers and a solar regulator to the EBL
630 B.
Flat vehicle fuses protect the various input circuits of the chargers. All outputs on the bus
modules are fused with polyswitch fuses.
The entire system is protected against:
F Excess temperature
F Overload
F Short circuit
ATTENTION!
Connecting the battery with inverse polarity poses of risk of damaging the electroblock.
System
devices
Protective
circuits
