12
CE-ERKLÄRUNG UND KONFORMITÄT
The tubular motor meets (item no. 20506/20510/20810/20820/20840/20507/20511/20811) the applicable requirements of
manufacturer.
Do not dispose of together with household waste! The tubular motors are recyclable and can
be deposited at a recycling center or a collection station for electrical household garbage.
WARRANTY CONDITIONS
We guarantee that our products are free from material and manufacturing defects. Excluded from the warranty are damages
that are caused by:
use-related, normal wear and tear
improper installation, connection, operation or treatment
improper maintenance and repairs by third parties
In case of a warranty case at our discretion we will repair the product, or exchange it for an equivalent SCHELLENBERG
product. Replacement or repair of the unit will not extend the warranty period! A condition for a warranty claim processing is
the presentation of the original sales receipt. When shipping the units please include a copy of the original sales receipt and
a description of the defect.
We grant a warranty for the quality of our tubular motors from the date of purchase, for a period of:
5 years, item no. 20506/20510/20810/20820/20840/20507/20511/20811.
TECHNICAL DATA
Item no. 20506/20507 20510/20511 20810/20811 20820 20840
Shutter system Mini Mini Maxi Maxi Maxi
Ø octagonal shaft 40 mm 40 mm 60 mm 60 mm 60 mm
Torque 6 Nm 10 Nm 10 Nm 20 Nm 40 Nm
max. duty cycle 4 minutes 4 minutes 4 minutes 4 minutes 4 minutes
max. Flat plastic
roller shutters
4,0 m² 6,0 m² 4,2 m² 8,5 m² 15 m²
Tensile force 15 kg 25 kg 20 kg 34 kg 60 kg
Rated power 98 watts 121 watts 113 watts 161 watts 218 watts
End-position adjustment Radio Radio Radio Radio Radio
incl. wall bearing 1 Comfort-Set 1 Comfort-Set 1 Comfort-Set 1 Comfort-Set 1 Comfort-Set
Warranty 5 years 5 years 5 years 5 years 5 years
max. Installation length 550 mm 550 mm 550 mm 550 mm 550 mm
