14
KEY EXPLANATION
Displays the current channel.
Flashes during the programming.
open button
Shutter moves upward.
stop button
Stops the up/down movement
of the tubular motor.
close button
Shutter moves downward.
channel selection button
This button can be used to select the
desired channel.
Front side Front side
5
1
1
3
3
4
4
2
2
Rear side
programming button
On/off switching of the
programming mode. The
button is located in the battery
compartment on the rear side of
the hand-held wireless remote
control.
Battery compartment
2x (AAA)
6
5-channel 1-channel
ACCESSORIES: HAND-HELD WIRELESS REMOTE CONTROL
20019/20022 20020/20024
20015/20021 20016/20023
The programming of the tubular motor is performed with the hand-held wireless remote control (accessory).
Suitable hand-held wireless remote controllers: 1-channel: 20015/20019/20021/20022 or 5-channel:
20016/20020/20023/20024.
