15
GB
APPLICATION EXAMPLES
1-channel
5-channel
K1
M 1
M 2 M 3 M 4 M 5
1K
by pressing the up-function button all tubular motors will perform an upward
movement at the same time
by pressing the down-function button all tubular motors will perform a downward
movement at the same time
die Endlagen bei den Rollläden können individuell eingestellt werden
M = roller shutter motor
K = channel
M = roller shutter motor
K = channel
M 1
M 2 M 3 M 4 M 5
K5
K4
K3
K2
K1
5K
pressing the channel selection button allows a switching between the tubular motors
by pressing the up-function button the respective tubular motor will perform an upward movement
by pressing the down-function button the respective tubular motor will perform a downward movement
