18
Voltage Input 220 V-240 V AC / 50 Hz
Output 24 V DC
Motor Motor voltage 24 V DC
Performance 50 W
Drive arm Linear spindle drive 2 Quantity
Speed without load 25 mm / sec.
Stroke 400 mm
Max. traction 2 x 2000 N
Max. gate weight 2 x 200 Kg
Max. gate width * 2 x 2,5 m
Min. gate width 2 x 1,2 m
Temperature range -20°C up to +50°C
operating cycles 15.000
Max. opening angle >120°
Emergency release Key
Control Soft start/stop Yes
Automatic force setting Yes
Gate open position 90° -> 120° depending on the installation situation
Gate closed position external mechanical stopper
Radio frequency 433,92 MHz
Range outdoors approx. 40 m
Dimensions Packaging 900 x 310 x 245 mm
Control 295 x 195 x mm
Drive 799 x 98 x 170 mm
Drive retracted 765 mm
Drive retracted 1165 mm
Accessories (optional) Art. No.
Light barrier 60030 / 60031
Key switch, surface-mounted 25101 / 25103
25102 / 25104
Radio coding switch 20058 / 20057
Inner key 60060 / 60061
Smartphone garage door opener 60999 / 60997
Wireless in-car transmitter 60859 / 60860
Hand-held wireless remote control DRIVE 60853 / 60852
Hand-held wireless remote control STANDARD 60854 / 60857
Hand-held wireless remote control PLUS 60855 / 60858
Hand-held wireless remote control PREMIUM 60856 / 60861
* without wind load
TECHNICHAL DATA
DIMENSIONS
29 mm
799 mm
765 mm
98 mm
117 mm
93 mm
46 mm
170 mm
400 mm
