LED LEGEND
LED1:
LED2: if the hand-held transmitter is activated, or the key switch or button is activated, then LED2 will be lit.
LED3:
LED4: the LED4 lights up as soon as the second light barrier is activated.
LED5: the LED 5 lights up as soon as a hand-held transmitter signal has been received.
Mo1+
Mo1-
Mo2+
Mo2-
L+
L-
Lo+
Lo-
+12V
G
F01
F02
F0+
G
D
S
G
LED1 SYSlearn
LED5
LED2 RFLED
LED3 Ph01
LED4 Ph02
